WEB GUIDE CONTROL SYSTEMS

System components 7Motor-driven actuator K12Motor-driven actuator K12-80-* *Model Output TolqueN・cmRated SpeedrpmThrustkNStrokemmSpeedmm/sMasskgRated voltageDCVAmbienttemperature°CAmbienthumidityProtectivestructureratingK12-00-70 Rotary 120 80* ― ― ― 1.224(1 A) 0 to +40°C 35-85% RH(no condensation)IP40K12-00-450 Rotary 30 450* ― ― ― 1.2K12-32-07 Linear ― ― 0.3 32 8* 2.9K12-32-20 Linear ― ― 0.15 32 40* 2.7K12-80-07 Linear ― ― 0.3 80 8* 3.1K12-80-20 Linear ― ― 0.15 80 40* 3.0K12-150-07 Linear ― ― 0.3 150 8* 3.7K12-150-20 Linear ― ― 0.15 150 40* 3.7* Note: Rated Speeds and speeds shown are when unloaded.Item Model Output TorqueN cmRated speedrpmThrustkNStrokemmRated speedmm/s (under no load)1 K12-00-70 Rotary type 120 80 ― ― ―2 K12-00-450 Rotary type 30 450 ― ― ―3 K12-32-07 Linear type ― ― 0.3 32 84 K12-32-20 Linear type ― ― 0.15 32 405 K12-80-07 Linear type ― ― 0.3 80 86 K12-80-20 Linear type ― ― 0.15 80 407 K12-150-07 Linear type ― ― 0.3 150 88 K12-150-20 Linear type ― ― 0.15 150 409 K50-150-20 Linear type ― ― 1.5 135 2010 K50-200-20 Linear type ― ― 1.5 185 2011 K50-150-20/A Linear type ― ― 1.5 135 2012 K50-200-20/A Linear type ― ― 1.5 185 2013 K62-150-20 Linear type ― ― 1.5 135 2014 K62-200-20 Linear type ― ― 1.5 185 2015 K62-200-20/A Linear type ― ― 1.5 135 2016 K62-200-20/A Linear type ― ― 1.5 185 2017 K80-00 Rotary type 200 100 ― ― ―? 18 A031-80-20 Linear type ― ― 0.3 80 22.5? 19 A031-150-20 Linear type ― ― 0.3 150 22.5? 20 A151-150-20 Linear type ― ― 1.5 135 24? 21 A151-200-20 Linear type ― ― 1.5 185 24? 22 A352-150-20 Linear type ― ― 3.5 150 20* Note: Items marked with ? are AC servo motor items.Table of actuatorsWe have translatory and rotary models in the K12 series.Both types are strengthened to withstand thrust loads.They are constructed to control thrust direction as muchas possible. The translatory motor-driven actuators have aplanetary gear and ball screw within a single structure, forstrength and precision.
